DSC-E3UW
Lens MTF Tester
DSC-E3UW is a specially designed MTF tester for a wide-angle lens inspection.
For the Ultra-Wide view angle test requirement, the new dome design supports up to 195˚ FOV without bracket changing needed. By providing high precision, repeatability with a reasonable cost inspection solution, and compatibility with the industry standard, DSC-E3UW is the first choice in R&D evaluation and incoming quality control.
APPLICATION
Highly suitable for automotive, sport, and surveillance applications.
FEATURES
✔ A single system can support amazingly large FOV 14˚ ~195˚ measurement.
✔ Replacing brackets is not needed when switches lens types between regular and Wide-Angle lenses.
✔ UMA Patent：DSC-E3WE supports various kinds of reticle patterns, such as Cross Line, on Distortion compensation and MTF measurement without additional reticle and optical information.
As a result, the calibration process and reticle cost can be significantly deducted.
✔ With an advanced optical system, DSC-E3UW supports measurement at infinity and finite object distance.
Furthermore, the shortest object distance can reach 20cm.
✔ For a user to be able to choose the most suitable focus-scanning mode freely, both free run and trigger run are available.
✔ A single tray can place 10 pieces of M12 lenses, and the time for the tray in and out is around 1.5 seconds.
Optiona Upgarde
✔ Upgrading the system for 5x Zoom Lens test is available.
Lens MTF Tester
DSC-E3UW is a specially designed MTF tester for a wide-angle lens inspection.
For the Ultra-Wide view angle test requirement, the new dome design supports up to 195˚ FOV without bracket changing needed. By providing high precision, repeatability with a reasonable cost inspection solution, and compatibility with the industry standard, DSC-E3UW is the first choice in R&D evaluation and incoming quality control.
APPLICATION
Highly suitable for automotive, sport, and surveillance applications.
FEATURES
✔ A single system can support amazingly large FOV 14˚ ~195˚ measurement.
✔ Replacing brackets is not needed when switches lens types between regular and Wide-Angle lenses.
✔ UMA Patent：DSC-E3WE supports various kinds of reticle patterns, such as Cross Line, on Distortion compensation and MTF measurement without additional reticle and optical information.
As a result, the calibration process and reticle cost can be significantly deducted.
✔ With an advanced optical system, DSC-E3UW supports measurement at infinity and finite object distance.
Furthermore, the shortest object distance can reach 20cm.
✔ For a user to be able to choose the most suitable focus-scanning mode freely, both free run and trigger run are available.
✔ A single tray can place 10 pieces of M12 lenses, and the time for the tray in and out is around 1.5 seconds.
Optiona Upgarde
✔ Upgrading the system for 5x Zoom Lens test is available.
2
FUNCTIONS
| MTF | 5 ~25 Image Regions |
| DOF | Depth of Focus |
| FBL | Flange Back Focal Length |
| EFL | |
| Through Focus | |
| Focus Tilt | Curvature Height |
| S.F.R. | Spatial Frequency Response |
| Tilt Angle | Optical Axis Tilt & Azimuth |
| Image plane Correction | Simulated Active Alignment |
| Limit Resolution | TV Line=2*LR*Sensor Size |
| C.R.A. | Chief Ray Angle |
| Encircle Energy | |
| FOV | (UMA Patent) |
| Optical Distortion |
3
SPECIFICATIONS
| Machine Dimensions | 950mm(D)*1400mm(w)*1600mm(L) |
| Machine Weight | 350 Kg |
| Power Supply | AC220V/10A |
| Software Operation | Windows 10 |
| Optical System | Infinity conjugate |
| Number of Collimators (or Image Regions) |
9~25 sets |
| Normally Average Test Time (Exclude tray load/unload) |
Without tray in/out is around 2.5s/lens Include tray in/out is around 3.0secs/lens |
| Reticle Pattern – 2 types (Optional) | Edge (ISO 12233) Cross Line |
| MTF Repeatability (Excluding load & unload) |
Delta MTF：(≦ 180lp/mm) On axis ≦1.5；Off axis ≦2.5 |
| Maximum Measuring Frequency | 500lp/mm |
| Limited FBL | > -3.0mm |
| Limited Image Circle | ≦12mm ( >12mm customized) |
| LED Light Source | Visible：Photopic NIR：850nm or 940nm (Optional) |
